KIBO Raptor

- automatic bollard with low installation height

KIBO Raptor Combines High Security with Flexibility. It Is the Most Resilient Bollard of Its Kind on the Market Due to Its Extra-Strong Interior

KIBO Raptor is both PAS 68 and ASTM tested and approved, capable of stopping a 7.5-ton truck at 80 km/h without experiencing any loss of functionality.

During the tests, a very low downward force transfer was measured, ensuring that underlying building structures are well protected in case of a collision.

Contact us for more information

High Security in a Unique Design

KIBO Raptor can be used individually or in a bollard system to secure an opening of any size.

The Raptor bollard is an impressive barrier that can easily integrate into modern architecture. The bollard is ideal for locations where there is a need for high-security solutions in a contemporary design.

High-security bollards are also known as vehicle barriers, anti-terror security, and Hostile Vehicle Mitigation (HVM).

Simple and Effective Installation

KIBO Raptor can be raised and lowered using standard control units and can also be equipped with the Hydra monitoring system, enabling detailed interaction with the device through a simple, streamlined interface. Additionally, it can be equipped with EFO (Emergency Fast Operation).

KIBO Raptor only requires an installation depth of 500 mm. There is no need for trapdoors or additional reinforcement, making the installation both simple and effective.

For KIBO Raptor to function and communicate, it requires the installation of a corresponding control cabinet, detection loops, and drainage. Our installers ensure that everything is installed in accordance with the installation requirements and your expectations.

Why Choose KIBO Raptor?

Zero penetration - Provides maximum standoff distance
Operational after collisions - Allows access for emergency vehicles
Continued protection after collisions
Reliable and easy to install
Turnkey solution

Specifications

Performance:
- ASTM: M50-P1 Zero penetration (SD-STD2.01 K12)
- ASTM: C40 P1 Zero penetration
- PAS68 Blocker/Bollard V/7500[N3]/80/90:3.3/18.9
Height (above ground): 985 mm
Width: 380 mm
Options: Emergency Fast Operation (EFO), Hydra monitoring system, Trace Heating, LED lights, Locking valve
Normal operational speed: Approximately 4-6 seconds
EFO (Emergency Fast Operation): Approximately 1.5 second
